OMRON CJ2H-CPU65-EIP Programmable Controllers OMRON CJ2H-CPU65-EIP

Unit type: CJ1 Basic I/O Units.
Product name: AC Input Units.
Specifications: I/O points, 16 inputs;
Input voltage and current: 100 to 120 VAC, 7 mA(100 V, 50 Hz);
Commons, 16 points, 1 common; External connection,
Removable Terminal Block; No. of words allocated, 1 word.
Current consumption: 5V, 0 OMRON CJ2H-CPU65-EIP. 09A; 24V, --.
Standards: UC1, N, L, CE.
A Wide Range of Basic Input,
Units for High Speed Input and,
Different Applications CJ2H-CPU65-EIP
Receive ON/OFF signals from external,
devices into the PLC System to update,
I/O memory in the CPU Unit.
New high-speed input models CJ1W-ID212 and,
CJ1W-ID233 are now available. These units can,
help to increase system throughput.
Product name: CJ-series I/O Control Unit OMRON CJ2H-CPU65-EIP.
Specifications: Mount one I/O Control Unit,
on the CPU Rack when connecting one or,
more Expansion Racks.
Connecting Cable: CS1W-CN@@3 Expansion,
Connecting Cable Connected Unit:
CJ1W-II101 I/O Interface Unit,
Mount to the right of the CPU Unit.
Current consumption: 5V , 0.02A;
24V, --.
Standards: UC1, N, L, CE.
Expand CJ/NJ-series with These Units.
To expand a CJ/NJ-series Controller,
connect an I/O Control Unit to the CPU Rack,
and I/O Interface Unit to the Expansion Rack,
and connect the two Units with I/O Expansion Cable OMRON CJ2H-CPU65-EIP. Unit type: CJ1 Basic I/O Units.
Product name: DC Input/Transistor Output Units OMRON Programmable Controllers.
Specifications: Output type, Sourcing;
I/O points, 16 inputs, 16 outputs;
Input voltage,Input current, 24VDC, 7mA,
24VDC, 0.5A Short-circuit protection;
Commons, 16 points, 1 common;
External connection, MIL connector OMRON Programmable Controllers.
No. of words allocated: 4 words.
Current consumption: 5V, 0.13A; 24V, --.
Standards: UC1, N, L, CE.
A Wide Range of Basic Mixed,
I/O Units for Different Applications,
and Wiring Methods.
One Mixed I/O Unit has connectors for,
both inputs and outputs OMRON Programmable Controllers.
Use Mixed I/O Units to easily ,
build space-saving systems. I/O capacity/Mountable Units(Expansion Racks): 2, 560 points/40 Units (3 Expansion Racks max.).
Program capacity: 60K steps.
CJ1H-CPU65H CPU Data memory capacity: 128K words(DM: 32K words, EM: 32K words × 1 bank).
LD instructionUnit type: CJ1 Basic I/O Units.
name: B7A Interface Units.
Specifications: I/O points, 32 inputs/outputs;
External connection, Removable terminal block.
No. of words allocated: 4 words.
Current consumption: 5V, 0.07A; 24V, --.
Standards: UC1, CE.
It transmitts 16 points of I/O signals per,
word with a pair of cables CJ2H-CPU65-EIP.
Easy and minimized wiring effort,
The B7A Interface Unit and B7A Link Terminal,
can be used in the same way as a standard,
Basic I/O Unit and I/O Terminal withoutt,
any need to worry about communications OMRON CJ2H-CPU65-EIP.
This characteristic reduces the wiring,
when using more than one relatively remote,
sensor or actuator.
