Proface GP4104W1D(GP-4104W) Monochrome model touch screen Proface GP4104W1D(GP-4104W)

Brand: Proface
Name: Monochrome model touch screen
Model: GP4104W1D(GP-4104W)
Display size: 3.4 inches.
Display color: STN monochrome LCD16 gray level.
Resolution: 200 x 80 pixels.
Backlight: White / Pink / red.
Touch screen type: resistance type (analog).
Storage space: 2.2MB.
Interface: ethernet.
Rated voltage: DC24V.
Backlight color scheme and interface type!
Two groups of 3 color backlight and serial port or Ethernet interface combination, a total of 8 models to choose from.
Horizontal or vertical installation options!
GP4100 can be installed horizontally or vertically, and can be used flexibly in many occasions.
Resolution of 200 x 80 pixels, small characters can be clearly displayed, so that the picture editing more flexible.
Image font support multi language features, can clearly and beautifully display a variety of languages.
You can display messages in an image font so that it is easy to read.
With bitmap fonts and image fonts can make the figures show more clearly.
The use of 16 gray level components, you can create a clear and easy to operate the screen.
Provide a variety of graphics for screen design selection, so that the running state at a glance.
Using 16 gray, can clearly show the JPEG and BMP images.
Can create a unique start screen.

NPN output type.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
LCD: monochrome.
Color: 16 levels of gray.
Ethernet interface: No.
Serial port: 1.
CANopen interface: No.
USB (host):1.
USB (device): none.
Built in DIO input: 16 points.
Built in DIO output: 16 points.
Built in AIO input: No Proface GP4104W1D(GP-4104W).
Built in AIO output: No.
Common DIO:2 point high speed counter (with synchronous output) pulse capture input, pulse output, PWM output GP4104W1D(GP-4104W)
Special DIO: No.
Expansion module EX module: up to 3.
Expansion module CANopen module: 63 stations.
Controller memory size: EPROM 132KB FLASH (equivalent to 15000 steps (up to 60000 steps).
Direct connection temperature controller with serial port.
Previously, the need to connect to the temperature controller PLC Proface GP4104W1D(GP-4104W).
The use of 5.7 inch models (LT3000 Series), with a serial port connected to the thermostat or other types of control cards,
Total equipment costs can be reduced. Connect the external device with the prepared sample picture.
Integrated design.
Adopt integrative design, compact structure,
When the installation is only required to open a hole in the panel 22mm Proface GP4104W1D(GP-4104W).
The display module or the control module can be easily replaced when the fault is eliminated.
Using remote monitoring software GP-Viewer or data acquisition software EX Pro-Server,
Can easily monitor the production scene of the man-machine interface screen, or release production orders and real-time data collection Proface Monochrome model touch screen.
Flexible installation.
The control module can be installed on the DIN guide rail by using the split installation cable,
And the display module is installed in other locations Proface Monochrome model touch screen.
Display module occupies a small space, even if the space is limited, but also can be flexible to install.
Connect various control devices.
Pro-face human machine interface can be connected to a variety of industrial controllers, including PLC, motion controller, robot and other equipment Proface Monochrome model touch screen.
Remote HMI Pro-face.
Natural connection production line and tablet PC or smart phone. By adding APP,
True implementation of mobile operations without loss of any operational performance.
Directly confirm the cause of the failure of the phone, as far as possible not to the scene on the recovery of the machine running.
In order to meet the needs of users for small control devices, Pro-face integrated control and operation functions in the human computer interface.
In short, is to indicate the lights, instruments and other display devices and switches, buttons and other operational functions to integrate into a compact PLC.
In addition to reducing wiring and saving space, the design also greatly reduces the use of electrical components,
Which ensures the long service life of the equipment.
The compact models are equipped with standard I/O, and they can be used as a special I/O.
High / low pulse with maximum 100kHz and maximum 65kHz of the high speed counter can be achieved by the advanced control.
Strong I/O interface not only supports the need to switch and indicator light equipment, but also supports the need for sophisticated positioning of complex equipment.
CANopen network
LT4000M supports data exchange with a variety of remote devices through the CANopen, easy to achieve economic and easy to use system design.
Can choose standard I/O module, also can choose action or control module and other more advanced products in complex application.
Use EX GP-Pro to easily test and debug the project.
EX GP-Pro simulation is a kind of offline simulation function, with the help of this function,
No need to connect the man-machine interface, you can test the operation of the screen and the logic program GP4104W1D(GP-4104W).
Compact size.
The volume is small but the display is fresh and bright, can create a rich and readable operation picture.

The control function of the whole and the digital I/O, analog I/O, analog temperature input and USB, serial port and Ethernet communication interface Proface GP4104W1D(GP-4104W).
