GP4106G1D(GP-4106G) Monochrome model touch screen Proface GP4106G1D(GP-4106G)

Brand: Proface
Name: Monochrome model touch screen
Model: GP4106G1D(GP-4106G)
Display size: 3.4 inches.
Display color: STN monochrome LCD16 gray level.
Resolution: 200 x 80 pixels.
Backlight: Green / orange / red.
Touch screen type: resistance type (analog).
Storage space: 2.2MB.
Interface: RS-422/485.
Rated voltage: DC24V.
Backlight color scheme and interface type!
Two groups of 3 color backlight and serial port or Ethernet interface combination, a total of 8 models to choose from.
Horizontal or vertical installation options!
GP4100 can be installed horizontally or vertically, and can be used flexibly in many occasions.
Resolution of 200 x 80 pixels, small characters can be clearly displayed, so that the picture editing more flexible.
Image font support multi language features, can clearly and beautifully display a variety of languages.
You can display messages in an image font so that it is easy to read.
With bitmap fonts and image fonts can make the figures show more clearly.
The use of 16 gray level components, you can create a clear and easy to operate the screen.
Provide a variety of graphics for screen design selection, so that the running state at a glance.
Using 16 gray, can clearly show the JPEG and BMP images.
Can create a unique start screen.

Specifications: DC24/H (handheld) class models.
Emergency stop switch: red.
Display type: STN pseudo color LCD.
Display size: 5.7 inches.
Resolution: 320 x 240 pixels (QVGA).
Display color: 4096 color.
Backlight: white LED (back light lamp replacement: return to repair).
Brightness adjustment: 16 level adjustment can be carried out by touch panel Proface GP4106G1D(GP-4106G).
Touch panel type: resistance type (analog) GP4106G1D(GP-4106G)
Error visualization.
The controller is directly connected to the GP, and the key error information of the controller can be displayed on the GP by using the sample unit.
No need to open the control panel, through the PLC to monitor the GP program.
Through the data through the GP function, you can easily debug the ladder program and adjust the data due to changes in the production line by GP easily Proface GP4106G1D(GP-4106G).
Can improve the efficiency of the 5 functions.
Using EX GP-Pro can easily create a clear picture and save the creation time.
Screen and logic programming software EX GP-Pro interface is very friendly,
The drag and drop feature makes the software interface easy to operate.
EX GP-Pro powerful features, such as 3D simulation components, image fonts and simulation functions,
Even beginners can easily and quickly grasp how to create a picture Proface GP4106G1D(GP-4106G).
Providing operation and maintenance instructions through video mode, which can save maintenance cost.
The operation and maintenance instructions provided by the video mode can make any operator easy to master the operation method Proface Monochrome model touch screen.
Easily upgrade Proface Monochrome model touch screen.
GP/ST series supports GP series of all models of the screen data, including the first generation of the GP10 series.
GP product family to maintain the size of the opening of the panel compatibility, to facilitate easy replacement.
Rich sample images can reduce programming time.
Pro-face provides a large number of sample images and 3D parts,
So you can easily create a beautiful and intuitive picture, in order to save editing time Proface Monochrome model touch screen. Data transmission using USB memory.
In the production site using USB memory can be easily transferred to the production line change and change the screen data.
Safety control function can minimize the problem of production site
Password management functions can be based on each operator or administrator password to enter the set level can be operated by the screen,
According to the function of the operator to set the password to enter the level.
In order to strengthen the management, the operator must enter the ID and the password to operate the equipment.
Use USB memory or CF card backup monthly and daily
Recording function using USB memory or CF card can easily improve the efficiency of daily and monthly.
The use of CSV data conversion function can be modified on the PLC GP settings.
Simulated running status on PC.
Use PC simulation function, do not need to transfer the picture to GP,
You can check all the functions off GP on the PC - including the screen operation, D script, logical script GP4106G1D(GP-4106G).
Remote operation and monitoring in the Office
In the office or other remote side can monitor the production site of the GP screen.
Without picturee editing or programming, you can achieve real-time management and monitoring, and now, you can also provide more efficient remote maintenance control Proface GP4106G1D(GP-4106G).
