MITSUBISHI FX5U-80MT/ESS FX5U-80MT/ESS

MITSUBISHI inverter FR-F720 series.
Voltage level: three phase 200V.
Frequency converter capacity: 0.75KW.
When the inverter is running, the starting current and starting torque of the motor are how?
With the operation of the inverter, with the acceleration of the motor to improve the frequency and voltage,
The starting current is limited to 150% below the rated current (according to the different types of aircraft, 125%~200%) FX5U-80MT/ESS
Starting with power frequency power supply, the starting current is 6~7 times of the rated current, therefore, the impact on the mechanical and electrical.
The inverter drive can be smoothly start (start time longer) MITSUBISHI FX5U-80MT/ESS.
The starting current is 1.2~1.5 times of the rated current, and the starting torque is 70%~120% rated torque;
For the inverter with the torque automatic enhancement function, the starting torque is more than 100%, which can start with full load . 1 axis servo amplifier.
MITSUBISHI general AC servo amplifier MELSERVO-J4 series.
Rated output: 3.5kw.
Interface: SSCNET III /H MITSUBISHI FX5U-80MT/ESS.
Power supply: three phase AC200V.
Servo amplifier supporting SSCNET III /H .
Complete synchronization system capable of using high speed serial optical communication.
Can be combined with the servo system controller to maximize the performance of the servo system.
Improve mechanical properties by high performance motor.
By improving the resolution and processing speed of the encoder,
The rotating servo motor has higher precision and better performance of rotation.
Only open a key type of adjustment function, can be carried out including mechanical resonance filter, high end seismic control II, low pass filter servo gain adjustment.
Easily start advanced seismic function, it can maximize the mechanical properties.
It can automatically adjust the required response settings automatically. Superior high efficiency IPM motor.
Output power: 2.2kw.
Rated speed: 1500r/min.
Voltage level: 400V.
IPM motor MM-EFS series can not be used to run the power frequency power.
The total wiring length of the IPM motor shall not exceed 100m.
1 inverters can not connect multiple IPM motors at the same time. Motor series: medium inertia, medium capacity.
Using a serial absolute / incremental encoder.
Rated output power: 3.0kw.
Rated speed: 1000rpm.
With the brake: without.
Shaft end: straight shaft.
The structure of the AC servo motor stator is bbasically similar to the capacitor split phase single-phase induction motor FX5U-80MT/ESS.
The stator is provided with two positions of 90 degrees of mutual difference of the winding, one is the excitation winding Rf, it is always connected to the AC voltage Uf;;
TThe other is to control the winding L, which is connected to the control signal voltage Uc FX5U-80MT/ESS.
So the AC servo motor, also known as the two servo motor.
FX5U-80MT/ESS Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=FX5U-80MT/ESS&select=5
