MITSUBISHI GT15V-75R1

Drive unit 200VAC/400VAC level.
MITSUBISHI motor general AC servo amplifier MELSERVO-J3 series.
Need conversion unit MR-J3-CR55K4) supporting the use of.
Rated output: 55kw.
Interface type: SSCNET type III fiber communication.
Special features: integrated driver security.
Power specification: three phase AC400V MITSUBISHI .
High speed serial communication between the SSCNET and the servo amplifier by using the fastest up to 0 GT15V-75R144ms communication cycle,
A fully synchronous control system can be constructed.
It is only necessary to insert the special optical fiber into the joint to form SSCNET III network, which greatly reduces the wiring work and reduces the possibility of false wiring MITSUBISHI .
Due to the adoption of the optical fiber communication, the anti noise ability can be greatly improved and the long distance wiring of 50 meters (maximum 800 meters x 16 axes) can be realized .
A servo amplifier to meet the full closed loop control function MR-J3-B-RJ006.
Suitable for mechanical servo optimization and adjustment!
More advanced optimization adjustment function and control function to maximize mechanical properties MITSUBISHI . Axis of control: 1.
A1SD70 is a kind of voltage output type single axis positioning control module,
Equipped with a servo motor can form a closed loop control system of precise positioning.
Its fastest positioning speed up to 400Kpps, the location of the 32 bit binary number (with a symbol bit).
Positioning units according to the specific application settings, such as the number of pulses, millimeters, inches or degrees. Input points: 4 points.
Weight: 0.02kg.
Function expansion board is used in the FX3SA, FX3S, FX3GA, FX3G, FX3GE on the small number of input and output extension of the product,
Can be built into PLC. Large capacity battery.4 axes, open collector output type.
2 axis /4 axis /3 axis linear interpolation.
2 axis interpolation.
Control unit: mm, inch, degree, pulse.
Location data: 600 data / axis.
Maximum pulse output: 200Kpps.
40 pin connector.
Positioning module.
Open collector output.
Differential driver output.
Baased on the use of open coollector outputs and differential drive output type 2 types MITSUBISHI GT15V-75R1.
Differential driver output type positioning module can transmit high speed instruction pulse (up to 4Mpps) to the servo amplifier reliably,
Transmission distance off up to 10 meters, to achieve high speed and high precision control MITSUBISHI GT15V-75R1.
(the command pulse of the open collector positioning module is highest 200kpps.)
GT15V-75R1 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GT15V-75R1&select=5
