410 Panel mounted inlet MENNEKES 410 Part No:410

Product Name:Connector PowerTOP® Xtra
Part No.:14229.
Ampere:63A.
Poles:4p
Voltage:400V.
Earth position:6h.
Hertz 50-60Hz.
Connection technology:Screw terminals, SoftCONTACT.
Contact:nickel plated contacts, highly heat resistant contact carrier MENNEKES 410.
Protection type IP67.
screw terminals 410
with rubberised grip area.
frame terminals.
with SoftCONTACT.
with highly heat resistant contact carrier.
cable gland and sealing.
strain relief and protection against kinking.
enclosure with thread lock.
two safety slides.Product Name:Wall mounted inlet
Part No MENNEKES 410. :335.
Ampere:16A.
Poles:4p.
Voltage:230V.
Earth position:9h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP44.
screw terminals.
enclosure base with stamped recess for quick cutting out MENNEKES 410. Connecting terminal with screw.
Integrated shell structure.
With cable gland and seal.
With stress release device to prevent the cable from breaking.
Current: 16A.
Pole number: 3p.
Voltage: 230V.
Location: 6h hour.
Hz: 50-60Hz.
Connection mode: screw connection MENNEKES Panel mounted inlet.
Contact: standard.
Protection level: IP67.Product Name:Panel mounted inlet
Part No.:815.
Ampere:16A.
Poles:5p
Voltage:400V MENNEKES Panel mounted inlet.
Earth position:6h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP44.
screw terminals MENNEKES Panel mounted inlet.
nickel-plated contacts.
a retaining nose to hold the hinged lid of the connector must be provided by the customer in order to ensure satisfactory locking.Product Name:Connector ProTOP
Part No.:195A.
Ampere:16A.
Poles:4p
Voltage:500V.
Earth position:7h.
Hertz 50-60Hz 410.
Connection technology:Screw terminals.
Contact:standard.
Protection type IP44.
screw terminals MENNEKES 410.
cable gland and sealing.
strain relief and protection against kinking.
enclosure with thread lock and safety slide.
