1479 MENNEKES Panel mounted receptacle MENNEKES 1479

Product Name:Cepex panel mounted receptacle
Part No.:4180.
Ampere:32A.
Poles:5p.
Voltage:400V.
Earth position: 6h.
Hertz 50-60Hz.
Protection type IP44.
screw terminals.
with labelling field.
with safety lock MENNEKES 1479.
two keys.
cannot be dismantled when locked.
on request with identical locks.
suitable for installation in cable ducts and columns 1479
with identical lock: part no. + index G.Product Name:Panel mounted receptacle
Part No.:1264A.
Ampere:63A.
Poles:3p.
Voltage:230V.
Earth position :6h.
Hertz 50-60Hz.
Connection technology:Screw terminals, SoftCONTACT.
Contact: standrad MENNEKES 1479.
Protection type IP67.
screw terminals.
SoftCONTACT.
straight.
receptacles with pilot contact: part no. + index P.Product Name:Wall mounted receptacle
Part No.:7217.
Ampere:16A.
Poles:4p.
Voltage:400V.
Earth position :6h.
Hertz50-60 Hz.
Connection technology:screw terminals MENNEKES 1479.
Contact:standard.
Protection type IP44.
screw terminals
switched.
mechanical DUO-interlock.
circuit breaker, K-characteristics.
receptacles can be padlocked.Product Name:Cepex wall mounted receptacle
Part No MENNEKES Panel mounted receptacle. :4168.
Ampere:32A.
Poles:4p.
Voltage:400V.
Earth position: 6h.
Hertz 50-60Hz MENNEKES Panel mounted receptacle.
Protection type IP44.
screw terminals.
with labelling field.
with safety lock.
two keys.
cannot be dismantled when locked.
on request with identical locks.
cable entry: 1 x M 25 with cable gland at top, 1 x M 25 to be cut out at the bottom, 1 x M 20 to be cut out at the back side, for cables 7 up to 13 mm Ø MENNEKES Panel mounted receptacle. Producct Name:Panel mounted receptacle
Part No 1479. :3333.
Ampere:16A.
Poles:5p.
Voltage:400V.
Earth position :6h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contaact: standrad MENNEKES 1479.
Protection type IP67.
screw terminals.
uniform fixing hole spacing.
