Sale 524 MENNEKES 524 Door Switches

Product Name:Compact network distributor
Part No.25715.
Fitted with :4 SCHUKO® 16A, 230V.
1 Cepex data port socket with 2 RJ45 connection module couplings,
type E-DAT module, port, cat.6, brand: BTR.
Connection/feeder cable：2 M 25 at the top (closed) 524.
1 M 25 at the bottom (with cable gland) 524
1 M 25 3 x 5-7 at the bottom (with cable gland).
(seal insert for 2 individual cables up to 8 mm Ø).
with terminal for 1 cable up to 5 x 4 mm².
Enclosure size:160 x 245 mm (H x W) 524.
Protection type:IP44 .
network enclosure made of AMAPLAST 524.
protection class IP 44.
top part electric grey RAL 7035 or yellow RAL 1021, bottom part black with screw-in nuts for installation of a floor-mounted base.
including a height-adjustable mounting rail.
cable gland set with multiple seal.Product Name:Panel mounted receptacle with TwinCONTACT
Part No.:3155.
Ampere:32A.
Poles:4p.
Voltage:400V.
Earth position :6h.
Hertz 50-60Hz.
Connection technology:Screwless - TwinCONTACT.
Contact: standrad.
Protection type IP44.
screwless spring terminals.
standard flange dimensions.
20° inclination.
receptacles are designed for adding an auxiliary contact switch.Product Name:Wall mounted receptacle
Part No.:128A.
Ampere:63A.
Poles:3p. .
Voltage:230V.

Earth position:6h MENNEKES 524.
Hertz50-60 Hz.
Connection technology:Screw terminals.
Contact:standard.
Protection type:IP67.
screw terminals.
with SoftCONTACT.
internal fixing.
one cable entry at top and two blind cable entries. (can be cut outt) at bottom MENNEKES 524.
enclosure base can be turned 180°.
with 6 fixing points to accommodate special terminals.
products with pilot contact: part no. + index P.
