MENNEKES 3154 Door Switches 3154

Product Name:DELTA-BOX receptacle combination
Part No.:92908.
Protection type:IP67.
pre-wired for installation.
with cable grip and installed hanging hook.
enclosure and insert made of AMAPLAST.Product Name:3KRAFT®
Part No MENNEKES 3154. :94351SI.
Fitted with:3 SCHUKO® 16A, 230V.
Connection/feeder cable:for 1 cable up to 3 x 6 mm² 3154
Protection type IP44.
pre-wired for installation.
back box in black MENNEKES 3154.
hinged cover available in red (RO), yellow (GE) or silver (SI) .
enclosure and insert made of AMAPLAST.Product Name:Panel mounted receptacle
Part No.:857.
Ampere:16A.
Poles:3p.
Voltage:230V.
Earth position :6h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact: standrad.
Protection type IP44 MENNEKES 3154.
screw terminals .
small flange dimensions.
20° inclination.Product Name:AMAXX® receptacle combination
Part No.:921260.
Fitted with:1 french/belg. standard 16A, 2p+E, 230V
1 CEE 16A, 2p, 20-25V.
Fusing:1 RCD 25A, 2p, 0.03A
1 MCB 6A, 2p, C
1 MCB 16A, 1p+N, C.
1 single phase transformer 230V/24V, 160VA.
Connection/feeder cable:for 1 cable up to 3 x 6mm².
Enclosure size:260 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation.
hinged to the side.
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.Product Name:Receptacle
Part No.768.
Ampere :16A.
Poles:4P.
Voltage:Isolating transformer.
Earth position:12 h.
Connection technology:Screw terminals.
Contact:standard.
Protection type:IP44 3154.
screw terminalls 3154.
internal fixing.
one cable entry at top and two blind cable entries (can be cut out) at bottom.
in 4 pole version enclosure base can be turned 180°.
