9142 MENNEKES Door Switches 9142

Product Name:AMAXX® receptacle combination
Part No.:930025.
Fitted with:1 CEE 32A, 5p, 400V
1 CEE 16A, 5p, 400V
3 SCHUKO® 16A, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
1 MCB 16A, 3p, C
3 MCB´s 16A, 1p, C
Pre-fuse max:32A.
InA :32A MENNEKES 9142.
RDF:1.
Connection/feeder cable:2 m H07RN-F5G4 with CEE-plug 32A, 5p, 400V 9142
Enclosure size:390 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation MENNEKES 9142.
hinged to the side .
enclosure and insert made of AMAPLAST.
fusing behind a transparent cover.Product Name:Connector AM-TOP®
Part No.:557.
Ampere:32A.
Poles:4p
Voltage:500V.
Earth position:7h.
Hertz 50-60Hz.
Connection technology:Screw terminals.
Contact:standard MENNEKES 9142.
Protection type IP67 .
screw terminals.
single part body.
cable gland and sealing.
strain relief and protection against kinking.Product Name:Grounding-type snap-in receptacle
Part No.:11665K.
Ampere :16A.
Poles:2P+E.
Voltage:230V.
Shutter:yes.
Connection technology:Plug-in terminals.
Contact:standard.
Prootection type:IP44 9142.
French-belgien standard.
without hinged lid.
3 plug-in termminnals as connecting terminals for 1 9142. 5 – 2.5 mm².
for easy installation in a cable duct or an enclosure.
for fixing on DIN rails with fixing rack 11254.
