75016 MENNEKES Door Switches 75016

Product Name:DELTA-BOX receptacle combination
Part No.:10859.
Protection type:IP68.
with cable grip.
pre-wired for installation.
with internal strain relief and installed hanging hook MENNEKES 75016.
enclosure and insert made of AMAPLAST.Product Name:Double Box with TwinCONTACT
Part No 75016:1648.
Ampere:16A.
Poles:4p.
Voltage:400V.
Hertz50-60 Hz.
Protection type:IP44.
screwless spring terminals
CEE and receptacle SCHUKO® in one enclosureProduct Name:Cable gland
Part No.41453. Type:M 25 MENNEKES 75016 MENNEKES 75016.
grey.
M25.
2 x 8, for 2 cables 6-8 mm.
matching all Cepex wall mounted receptacles.Product Name:Panel mounted receptacle with TwinCONTACT
Part No.:1641.
Ampere:16A.
Poles:4p.
Voltage:>50-500V.
Earth position :2h.
Hertz>300-500 Hz.
Connection technology:Screwless - TwinCONTACT.
Contact: standrad.
Protection type IP44.
screwless spring terminals.
suitable for through wiring.
flange: 73,5 x 64 mm.
fixing hole spacing: 60 x 52 mm.
20° inclination.Product Name:AMAXX® automation enclosure
Part No.25505.
Fitted with:2 SCHUKO® 16A, 230V
Triple data enclosure
with transparent cover (lockable)
3 x liftable DIN-rails
1 x mounting plate 230 x 166 mm, mounted
1 x mounting plate 130 x 166 mm, mounted
1 x empty tube 19 mm Ø (for separation).
Fusing:1 RCD 25A, 2p, 0.03A
2 MCB´s 16A, 1p, C
1 glas tube fuse T 6,3A (controller fuse).
Connection/feeder cable:for 1 cable up to 5 x 10 mm².
Enclosure size:650 x 225 mm (H x W) 75016.
Protection type:IP 44.
top part grey RAL 7035 or yellow 1021.
bottom part black with screw-in nutss ffor installation of a floor-mounted base 75016.
including a height-adjustable mounting rail.
with mounting rail catches.
cable gland set with multiple seal.
