FX3SA-14MT-CM Weight: 03KG MITSUBISHI FX3SA-14MT-CM

Input signal: thermocouple type K or type J.
Applicable PLC:FX1N, FX2N, FX3U, FX2NC (to FX2NC-CNV-IF).
Applicable PLC:FX3UC (to FX2NC-CNV-IF or FX3UC-1PS-5V).
Thermocouple type temperature sensor input module.
Thermocouple type (K type, J type) temperature sensor input module.
4 channels can be entered FX3SA-14MT-CM.
Unit can be set to Celsius or fahhrenheit.
Resolution is K type 0.4 degree, J type 0.3 degree of high precision. Input signal power: 40mA. DC24V
Axis of control: 1.
Output frequency: Max 200kHz FX3SA-14MT-CM.
Weight: 0.2kg.
FX3U-1PG is a pulse output module of the maximum output 200kHz pulse train.
7 operation modes needed to take the simple position control.
The speed and the target address can be changed in the positioning operation according to the operation of the project,
Support near S shape plus deceleration FX3SA-14MT-CM. High speed positioning can be carried out smoothly.
Up to 8 units can be connected to FX3U or FX3UC.
Connecting FX3UC requires FX2NC-CNV-IF or FX3UC-IPS-5V.
Input and output points: 14 points.
Power supply: AC100-240V MITSUBISHI FX3SA-14MT-CM.
Input points: 8 points.
Output points: 6 points.
Output form: transistor output (drain).
Power consumption: 19W.
Weight: 0.3KG.
Outline dimension: 60x90x75mm.
A new application model.
FX3SA is a basic model on the basis of the basic performance of FX1S above the expansion of the expansion of the new model MITSUBISHI FX3SA-14MT-CM.
FX3SA is applicable to all kinds of fields of small scale equipment which need to simulate the quantity and function of MODBUS and Ethernet.
Basic models suitable for small scale control.
Compact but powerful,
At the same time, the analog quantity and communication function, etc MITSUBISHI FX3SA-14MT-CM.. Function expansion board for RS-232C communication.RS-232C/RS-422 converterMax input / output points: 30 points.
Power supply voltage: 24VDC.
Input points: 16 points.
Output points: 14 points.
Output type: relay.
Power consumption (W): 8.
Weight (kg):0.35.
Size (WxHxD) mm:100x90x49.
Host has 10 points (6I/4O), 14 points (8I/6O), 20 points (12I/8O), 30 points (16I/14O) of 4 types.
This type of PLC is mainly used in all of the digital input, digital output control point of the device.
Can be directly connected to the 220V city power, built-in 8K step EEPROM memory, no battery, easy to maintain.
The series transistor output (MT) of the PLC, can be output 2 100KHz pulse, direct drive servo or stepper motor.
The series PLC can not be brought with the expansion module, but can be installed by the BD board to extend a small amount of I/O.
The series 1N through the installation of BD series PLC board, can achieve RS232, RS485, RS422 communication.
All equipment is digital input and output point. The total I/O points are not more than 30 points, and the input points are less than 16, the output points are less than 14 FX3SA-14MT-CM.
Its MT series of PLC can drive 2 way servo or stepper, commonly used in the control system for a simple manipulator.
